How to Diagnose OPEL CORSA-B with OP-COM CAN OBD2?
Which Tool you need: Opcom OP-COM 2012V Can OBD2 for OPEL
Vehicle model: Opel CORSA-B
Software Version: 2012 Firmware Version: 1.59
OPCOM 2010V Software Feature:
- OPCOM is a special PC Based diagnostic interface especially for OPEL.
- Cover almost all Opel cars, even new cars with CAN-BUS based diagnostic, such as Vectra-C, Astra-H, Zafira-B.
- Let you to read out and clear fault codes, shows you live data, let you to perform output test. Fault codes will be shown with all available information.
- Support many control units (examples shown below)
Engine, Automatic Transmission, ABS, Airbag, Engine Cooling module, Instrument Cluster, Electronic Climate Control, Body Control Unit
Notice: Do not Update It online, it will damage the OP-COM.
Step by step instruction:
Install OP-COM software and Connect Op-com diagnostic interface with Opel CORSA-B via OBD socket
Select Diagnostics from main menu
Choose [1999] -> [Corsa-B] -> [Engine] -> [X 12 XE], then wait until the system detects control unit parameters.
Check and confirm vehicle information and press [Fault Codes] to continue.
Fault codes are all listed out as shown below
Click [Back] to return to previous menu and [Close] to next step
Select [Body] control module
Select [Immobilizer]
Wait until the system detects control unit parameters.
Go back to the main menu or exit the Op-com software if complete ECU programming procedures.
If you want to know about Op-com V2012 Software free Download & Update, please visit this website:
http://blog.worldobd2.com/2015/09/22/op-com-v2012-software-free-download-updateinstallation-guide/
